| সনাক্তকরণ নীতি: | বিচ্ছুরণ | মাত্রা: | 90 মিমি * 60 মিমি * 33 মিমি (দৈর্ঘ্য * প্রস্থ * বেধ) |
|---|---|---|---|
| গ্যাস সনাক্ত: | CL2 | পরিমাপ পরিসীমা: | 0-10 পিপিএম 0-50 পিপিএম |
| রেজোলিউশন: | 0.01 পিপিএম | ওজন (ক্লিপ সহ): | 125 গ্রাম |
| নির্ভুলতা: | ≤ ± 2-5%fs | অ্যালার্ম মোড: | শব্দ, আলো, কম্পন বিপদাশঙ্কা |
| ওয়ার্কিং এয়ার প্রেসার: | 86 থেকে 106 কেপিএ | প্রতিক্রিয়া সময় (T90): | 15 থেকে 30 এর মধ্যে |
| সুরক্ষা ক্লাস: | আইপি 66/68 | কাজের তাপমাত্রা: | -20 ℃ থেকে 55 ℃ ℃ |
| নীতি: | ইলেক্ট্রোকেমিক্যাল নীতি | বিস্ফোরণ-প্রমাণ শংসাপত্র: | আইসেক্স, অ্যাটেক্স |
| কর্মরত আর্দ্রতা (নন-কনডেনসিং): | 0-95% RH | প্রদর্শন: | গ্যাসের নাম, ব্যাটারির শক্তি, ঘনত্ব একক, পরিমাপিত মান |
| বিদ্যুৎ সরবরাহ মোড:: | 3.6V শুকনো ব্যাটারি (নন-রিচার্জেবল এবং পরিবর্তনযোগ্য) | অ্যালার্ম টাইপ: | লো অ্যালার্ম, হাই অ্যালার্ম, STEL, TWA, কম ব্যাটারি ঐচ্ছিক ক্রমাঙ্কনের কারণে এবং বাম্প টেস্টের কারণে |
The MiniMeta Portable CL2 Gas Detector is a high-precision portable gas detector designed for chlorine detection using diffusion detection principle, specifically engineered for industrial safety applications in wastewater treatment plants and similar environments.
This IECEX/ATEX/EMC certified single-gas detector can detect hundreds of user-selected toxic gases. User-friendly and easy to operate, it features replaceable battery and sensor for long-term protection, offering a low-cost, long-term ownership gas monitoring system.
| Parameter | Specification |
|---|---|
| Detect gas | CL2 (Chlorine) |
| Sensor type | Electrochemical |
| Sampling method | Diffusion |
| Measure range | 0-10ppm / 0-50ppm |
| Resolution | 0.01ppm |
| Precision | ≤± 3% F.S. |
| Response Time | ≤30s (T90) |
| Display | Gas name, concentration unit, measured value, battery level |
| Alarm mode | Sound, light, vibration alarm |
| Alarm type | Low alarm, high alarm, STEL, TWA, low battery |
| Operating language | Chinese/English |
| Size | 90×60×33mm |
| Weight | 125g |
| Working Temperature | -20ºC to 50ºC |
| Working Humidity | 0-95%RH |
| Working air pressure | 86-106kpa |
